DGS-40, 50, 60E mobile single roll slag crusher

Name:DGS-40, 50, 60E mobile single roll slag crusher

Details
DGS-40, 50, 60E mobile single roll slag crusher

Brief introduction:

The host of sds-40e mobile single roll slag crushing machine adopts our company's excellent product -- DGS -- 40E single roll slag crushing machine. In addition to the excellent performance of the original host, the machine has the following new structural features:
The overload safety protection device adopts mechanical safety clutch to make the equipment overload rear barrier faster. The safety performance of the equipment is fully guaranteed.
As a result of the equipment bottom added rolling wheel, its maintenance is very convenient, save labor, effort.
The DGS-40E model is used for slag removal of power station boilers below 1000t/h, while the DGS-50 and 60E model are used for slag removal of power station POTS above 1000t/h.
DGS series mobile single roll slag crushers are not suitable for strong corrosion of water. They can also be used to break other materials, such as limestone, coal, etc.

Technical parameters:


序号 项目 型号 DGS-40E DGS-50E DGS-60E
1 碎渣量 40t/h 50t/h 60t/h
2 破碎粒度 ≤40mm
3 主轴转速 32r/min
4 入口尺寸 678×846(mm) 878×846(mm) 1078×846(mm)
5 出口尺寸 618×440(mm) 818×440(mm) 1018×440(mm)
6 电机功率 7.5kw 11kw 11kw
7 过载切断电流 <10s <10s <10s
8 自动排障次数 3~4次 3~4次 3~4次
9 外形尺寸 2702×1040×700(mm) 2920×1040×700(mm) 3120×1040×700(mm)
10 过载保护 4.7kg-m脱开 7kg-m脱开 7kg-m脱开
