DGS-40, 50, 60 single roll slag crusher
Brief introduction:
DGS-40, 50 and 60 single roll slag breaker is the first new generation power station boiler slag breaker developed independently in China in the early 1980s. The product has been verified by many users all over the country and has a better life than imported products. It has been a subsidiary product since 1985.
The outstanding performance of DGS-40, 50 and 60 single roll slag crusher is as follows: long service life of the tooth plate, high degree of automation, and our company's independent development of proprietary technology - electronic automatic discharge and electronic protection device, which makes the equipment reach the international advanced level.
DGS-40, 50, 60 series of slag crushing machines currently have three specifications, two transmission modes: chain drive and coupling drive.
The DGS-40 is used for power station boilers below 1000t/h. The DGS-50 and DGS-60 are used for power station boilers above 1000t/h.
DGS-40, 50 and 60 slag crushers are not applicable for situations where water quality is highly corrosive. This machine can also be used for the crushing of other materials: limestone, coal, etc.
Technical parameters:
序号
|
项目 型号
|
DGS-40
|
DGS-50
|
DGS-60
|
1
|
碎渣量
|
40t/h
|
50t/h
|
60t/h
|
2
|
破碎粒度
|
≤40mm
|
3
|
主轴转速
|
32r/min
|
4
|
入口尺寸
|
678×846(mm)
|
878×846(mm)
|
1078×846(mm)
|
5
|
出口尺寸
|
618×440(mm)
|
818×440(mm)
|
1018×440(mm)
|
6
|
电机功率
|
7.5kw
|
11kw
|
11kw
|
7
|
过载切断电流
|
<10s
|
<10s
|
<10s
|
8
|
自动排障次数
|
3~4次
|
3~4次
|
3~4次
|
9
|
外形尺寸
|
2702×1040×700(mm)
|
2920×1040×700(mm)
|
3120×1040×700(mm)
|
10
|
质量
|
2160kg
|
2460kg
|
2830kg
|
