Ypl-2, 3 disc dredger

Name:Ypl-2, 3 disc dredger

Details
Brief introduction:
Ypl-2 and type 3 disc dredge not only has the advantages of general disc dredge, such as safety and reliability, simple operation and maintenance, water seal chamber, wet slag removal, etc., but also has the advantages of compact structure, high life, difficulty in blocking, strong overload capacity, flexible installation and arrangement, and convenient removal. The machine has a certain capacity of slag break, when the equipment overload operation can automatically alarm.
Technical parameters:

序号 项目 型号 YPL-2型 YPL-3型
1 额定捞渣量t/h 2 3
2 圆盘直径mm 1060 1280
3 圆盘转速r/min 1.14 1.71
4 圆盘转向(俯视) 顺时针 顺时针
5 圆盘额定扭矩N.m 1700 1700
6 瞬时最大扭矩N.m 5000 5000
7 电机功率kw 1.1 1.5
8 外型尺寸(包括渣斗)mm 1500×1300×1100 1770×1640×1345
9 总质量(包括渣斗)kg 1250 1500
