ZC series slag bin

Name:ZC series slag bin

Details
Brief introduction:

ZC series slag bin is mainly used for short-term storage of boiler ash slag to facilitate transportation of ash slag by vehicle. This series of general and scraper slag storehouse in dregs machine supporting the use, can store temperature below 100 ℃ ash, also can be stored and drain water wet slag. The series slag bin has the advantages of strong structure, large capacity and short construction period. The discharge port of this series of slag storehouse is equipped with electric jaw switch, which can be opened and closed reliably, convenient for maintenance and high degree of automation.


Technical parameters:


型号
有效容积m3 结构类型 水平尺寸mm 高度尺寸L mm 参考质量kg
ZC50 50 单体 6000×6000 12500 19500
ZC75 75 单体 6000×6000 13500 21000
ZC100 100 双体 6000×11000 12500 37500
ZC125 125 双体 6000×11000 13000 39000
ZC150 150 双体 6000×11000 13500 40500
